| Model No. |
D-300 Storm Series |
| 5.25" Bay |
4x 5.25" ( if you need more internal bay - iStorm7 Series ) |
| 3.5" Bay |
2x 3.5" 2x 3.5" (internal) |
| M/B factor |
12" x 9.6" ATX M/B |
| Switches : |
Power ON/OFF, System & Alarm Reset |
| Indicators : |
LEDs for Power ON/OFF, HDD, Fan & Alarm |
| Air Filter : |
Removable & Washable |
| Fan & Temp. |
Detecting Board For System Environment Monitoring
(Optional ) TC-ISF08 |
| Ventilation |
1 x 60mm Ball Bearing Fan ( Standard )
2x80mm;1x 60mm Ball Bearing Fans ( Optional ) |
| Material & Security : |
1.2mm SECC Zinc-Coated Steel (Japan Made)
Both Front Doors (Aluminum) Are Lockable |
| Dimension |
19"(W) x 20"(D) x5.25"(H) |
| Front Access Connector : |
USB 2.0 Port |
| I/O Ports |
Stardard ATX Port |
| Safety Standard: |
FCC/CE to chassis and FCC/CE/UL/TUV to power supply |
| Power Supply |
I-Star 3U 300w/400w/460w
I-Star 2U 350w/400w/460w Redundant power supply |
